Product Details:
|
| Vertical Wire Distance: | 15cm | Series: | PVC Coated |
|---|---|---|---|
| Zinc Coated: | 245g/m2 | Type: | Fixed Knot |
| Height: | 1.2m | Length: | 50m |
| Packing: | Plastic Film | Tensile Strength: | 1400N/mm2 |
| Application: | Highway Environment | Standard: | ASTM A121 |
| High Light: | PVC Coated Metal Farm Fence,50m knotted wire fence,PVC Coated knotted wire fence |
||
Line wires |
Type |
specification |
Edge wire diameter |
Inner wire diameter |
Mesh length |
7 |
7/150/813/50 |
102+114+127+140+152+178 |
2.5mm |
2.0mm |
50m(100m) |
8 |
8/150/813/50 |
89+89+102+114+127+140+152 |
2.5mm |
2.0mm |
50m(100m) |
8 |
8/150/902/50 |
89+102+114+127+140+152+178 |
2.5mm |
2.0mm |
50m(100m) |
8 |
8/150/1016/50 |
102+114+127+140+152+178+203 |
2.5mm |
2.0mm |
50m(100m) |
8 |
8/150/1143/50 |
114+127+140+152+178+203+229 |
2.5mm |
2.0mm |
50m(100m) |
9 |
9/150/991/50 |
89+89+102+114+127+140+152+178 |
2.5mm |
2.0mm |
50m(100m) |
9 |
9/150/1245/50 |
102+114+127+140+152+178+203+229 |
2.5mm |
2.0mm |
50m(100m) |
10 |
10/150/1194/50 |
89+89+102+114+127+140+152+178+203 |
2.5mm |
2.0mm |
50m(100m) |
11 |
11/150/1422/50 |
89+89+102+114+127+140+152+178+203+229 |
2.5mm |
2.0mm |
50m(100m) |
|
|
Top & Bottom Line |
Intermediate Line |
|
|
|
Line Wires |
Wire Dia (mm) |
Wire Dia(mm) |
Distance between |
Roll Height ( cm) |
Roll Length(m) |
6 |
2.5 |
2.0 |
15 |
60 |
50 |
6 |
2.5 |
2.0 |
15 |
80 |
50 |
8 |
2.5 |
2.0 |
15 |
80 |
50 |
9 |
2.5 |
2.0 |
15 |
80 |
50 |
8 |
2.5 |
2.0 |
15 |
100 |
50 |
11 |
2.5 |
2.0 |
15 |
100 |
50 |
9 |
2.5 |
2.0 |
15 |
120 |
50 |
13 |
2.5 |
2.0 |
15 |
120 |
50 |
13 |
2.5 |
2.0 |
15 |
150 |
50 |
15 |
2.5 |
2.0 |
15 |
150 |
50 |
17 |
2.5 |
2.0 |
15 |
200 |
50 |
Other special specification is available by customer request. |
|||||
Metal Farm Fence specification |
|
Name |
farm field fence cattle fence from china/cattle shelter/cattle panels heavy duty |
Materia |
Electric galvanized iron wire, Hot dipped galvanized iron wire, High tensile steel wire |
Surface Treatment |
hot-galvanized,cold-galvanized |
Application |
Field fence is a kind of mesh used in cattle, goat, deer, and pig. It is used for grassland, pastures,protection of ecological projects, protecting grassland, forestry, highway, etc. |
Features |
Simple in structure, Easy maintenance, Short installation period, Less weight, Easy for transport,and Good ventilation. |
Zinc coating |
normally 60-100g per square meter, max 230-240g per square coating |
Diameter |
1.8-2.5mm(, inner wire ) 1.8-3.5mm( outer wire) |
Height |
0.8m, 0.9m, 1.0m, 1.1m, 1.2m, 1.5m,1.8m,2m,2.4m |
Length |
25m-200m |
