ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16"

Large Image : ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16"

Product Details:

Place of Origin:	Hebei P.R. China.
Brand Name:	X MESH
Certification:	ISO9001:2015
Model Number:	X MESH-0213

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	USD0.70-5.50/PC
Packaging Details:	Wrapped with plastic film and pallet packing
Delivery Time:	5-7days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	19850m2/week

Contact Now

ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16"

Description

Standard:	ASTM A641	Cross Wire Spaced:	16"
Application:	Building Construction	Length:	10'
With:	2"	Wire Gauge:	9
Color:	Silver	Series:	Electro Galvanized
Tensile Strength:	80,000 PSI	Yield Point:	70,000 PSI
High Light:	ASTM A641 Construction Wire Mesh , ASTM A641 wire mesh for concrete walls , wire mesh for concrete walls 16"

ASTM A641 Standard Cross Wire Spaced 16" building construction Ladder Mesh

Ladder Mesh Introduction:

Ladder Mesh is a prefabricated reinforcement for embedment in the horizontal mortar joints of masonry.

It is manufactured in 10′ 8″ lengths from wire conforming to ASTM A 82 / A82M for cold drawn steel wire.

It consists of two or more parallel and deformed longitudinal wires welded to a perpendicular cross wire spaced 16″ O.C. Out-to-out spacing is approximately two inches less than the nominal thickness of the wall.

MATERIAL : Iron wire & stainless steel wire 304/316
Qijie metal joint reinforcement products conform to:
ASTM A951 (Standard Specification for Steel Wire for Masonry
Joint Reinforcement)
Our products pass the testing of ASTM A951,We tested in USA .
Tensile Strength - 80,000 p.s.i. | Yield Point - 70,000 p.s.i. minimum
Zinc Coating:
Mill Galvanized coating: (0.1 oz/ft²)
Hot-Dip Galvanized after fabrication: (1.5 oz/ft²)
Wire Diameter:
9 gauge or 3/16”Ø
Side Rods and Cross Rods available in any combination of the above.
Cross Rods welded 16” O.C.
Block Size: Standard Sizes: 4” wall - 16“ wall.
Other widths available on special request.

Ladder Mesh Standard Specification:

ITEMS #	Block width	Mesh width	Weight(KGS)	PACKING
QJM2	4''	2''	0.57	50PCS/BDL,20BDL/PALLET
QJM4	6''	4''	0.61	50PCS/BDL,20BDL/PALLET
QJM6	8''	6''	0.64	50PCS/BDL,20BDL/PALLET
QJM8	10''	8''	0.68	50PCS/BDL,20BDL/PALLET
QJM10	12''	10''	0.71	50PCS/BDL,20BDL/PALLET

Standard Length	Width	Finishes
10’(3.05m)	2”(50mm)	Uncoated Electro Galvanized Hot Dipped Galvanized After Fabrication Stainless Steel
	4”(100mm)
	6”(150mm)
	8”(200mm)
	10”(250mm)
All products conform to: ASTM A641 - (Electro galvanized ) ASTM A153 Class B2 - (Hot dipped after fabrication) ASTM A 82 - (Cold drawn steel wire) Tensile Strength:80,000 PSI;Yield Point:70,000 PSI minimum;Reduction of Area:30 %. ASTM A951-96 - (Masonry wall reinforcing) ASTM 580 Type 304 - (Stainless steel)

Ladder Mesh Feature :

* Greatly reduces cracking that can arise from thermal stresses. This enhances resistance to water penetration, as cracks are controlled.

* Increases lateral flexural strength.

* Bonds exterior and interior masonry wythes together in composite or cavity walls. Also bonds masonry at intersecting walls and corners

* Increases elasticity and performance of masonry walls under various stresses

Ladder Mesh Application:

Concrete slabbing, roads, paving, foundations, marine work, bank strong rooms, partition slabs, concrete block work, asphalt guttering and so on

ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16" 0

ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16" 1

ASTM A641 Construction Wire Mesh For Concrete Walls Spaced 16" 2
