Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade

China Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade supplier
Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade supplier Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade supplier

Large Image :  Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade

Product Details:

Place of Origin: China,Hebei
Brand Name: JINDEXIN
Certification: ISO9001:2008,ISO14001:2004,OHSAS18001:2007
Model Number: JDX12-6

Payment & Shipping Terms:

Minimum Order Quantity: 5000sqm
Packaging Details: 78rolls per 40HQ
Delivery Time: 20days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Contact Now
Detailed Product Description
Product Name: Woven Stabilization Fabric Model: PP40-28
Type: Woven Size: 6.0M*200M
Weight: 200g/sqm Application: Soil Reninforcement

Tensile Strength 80/80KN Woven Polypropylene Geotextiles  Used For Foundation Subgrade





Description:



Our factory offers a wide range of woven geotextiles for stabilization and soil reinforcement applications. These geotextile are cost-effective reinforcement elements which improve and enhance modern construction techniques in a variety of civil engineering applications. Environmental applications include liner support, voids bridging, and reinforcement over soft, hazardous pond closures. For any application where long term design of earth reinforcement structure are involved, wowen polypropylene geotextiles are a logical choice.



Woven geotextiles are engineered material suitable for subgrade stabilisation and base reinforcement applications,they are composed of high modulus polypropylene firbres,assembled to form a structured and stable woven geotextile.Continuous filament woven geotextile is using the polypropylene as the material has the merits of low weight, high reinforcement, low elongation, easy installation, low price, etc. And it can be fixed with one side or two sides of needle punched geotextile to form reinforcement geotextile.



Applications:



Because of their flexibility and versatility, woven geotextiles are used in a variety of applications, including enbankments on soft foundations, retaining walls, steepened slopes, and soil stabilization for road and rail construction.



Specifications:


Woven Geotextile Technical Data



No. Items 20-15 30-22 40-28 50-35 60-42 80-56 100-70 KN
Tensile strenth warp 20 30 40 50 60 80 100
weft 15 22 28 35 42 56 70
Elongation at break warp &welf 28% 28% 28% 28% 28% 28% 28%
Trapezoid tear strength long direction 0.3 0.45 0.5 0.6 0.75 1 1.2
Static puncture resistance   1.6 2.4 3.2 4 4.8 6 7.5
Vertical permeability cm/s 10-1 -10-4
Equivalent aperture O95,mm 0.08-0.5mm
weight/unit g/m2 120 160 200 240 280 340 400 +/-10%
UV strength retention % according to contract
others Width and length can be customized by clients. all the information can be consulted,clients can order according to actually design.



Feature advantage:



Color: Black / Customized

Temperature Range: 0°C ~ +150°C

Durability: The characteristics of synthetic fiber is not easy to be denatured .It can keep its original features.

Storage and transportation is convenient: Because of light weight, packing can be according to certain requirements, so the transport, storage, construction is very convenient .



Durable Woven Geotextile Fabric Tensile Strength 80/80 KN For Foundation Subgrade
