Product Details:
|
Product: | Stainless Steel Welded Wire Mesh | Material: | SS304 |
---|---|---|---|
Wire Gauge: | 14# | Aperture: | 1/2'' X 1/2'' |
Height: | 48" | Length: | 100' |
Feature: | Excellent Rust Resistance | Color: | Light Silver |
Application: | For Wall Cladding | Packing: | Waterproof Pater And Platic Film |
High Light: | 14 gauge stainless weld mesh,construction 304 stainless weld mesh,stainless steel welded wire mesh 1 2inch |
Stainless steel welded wire mesh specifications are popular and are often available from stock or can be quickly manufactured.
The welded wire mesh specifications featured here are popularly requested items that many professionals use in the building and construction industry. Keep in mind the list of items here is not exhaustive.
Product Name | Stainless Steel Welded Wire Mesh | |
material | SUS 201,304,316,316L,310S,904L.... | |
Aperture (inch) | Aperture(mm) | Wire diameter(BWG) |
1/4"X1/4" | 6.35mm x 6.35mm | 22, 23, 24 |
3/8"X3/8" | 9.52mm x 9.52mm | 19, 20, 21, 22 |
1/2"X1/2" | 12.7mm x12.7mm | 16, 17, 18, 19, 20, 21, 22, 23 |
5/8"X5/8" | 15.87mm x 15.87mm | 18, 19, 20, 21 |
3/4"X3/4" | 19.05mm x 19.05mm | 16, 17, 18, 19, 20, 21 |
1"X1/2" | 25.4mm x12.7mm | 16, 17, 18, 19, 20, 21 |
1"X1" | 25.4mm x 25.4mm | 14, 15, 16 |
1"X2" | 25.4mm x 50.8mm | 14, 15, 16 |
2"X2" | 50.8mm x 50.8mm | 12, 13, 14, 15, 16 |
· Infill panel & railing systems
· Industrial fan & machine guards
· Security enclosures
· Animal retention (cages)
· Small critter control
· Decorative signage
· Room dividers
· Wall cladding
· Ceiling panels
· Air vents & soffit screens
· Basket fabrication
· Food applications
· Racking & storage
· Aviary & bird screen
· Industrial separation
