Product Details:
|
Product Name: | Woven Wire Mesh | Material: | Copper Alloy Wire |
---|---|---|---|
Wire Diameter: | 3.5mm | Mesh Opening: | 35 × 35 Mm |
FCR: | 15% Improvement | Feed Use: | 10% Reduction |
Antibiotics: | 31% Reduction | Labor Hours/tonne: | 79% Reduction |
Characteristic: | Significantly Strong Support Structure. | Feature: | Large Inner Space Provides Water Flow And Circulation. |
Highlight: | 3.5mm woven wire mesh,35mm x 35mm opening woven wire mesh,fish production woven copper mesh |
Product Name |
Woven Wire Mesh |
Material |
Copper alloy wire |
Wire Diameter |
3.5mm |
Mesh Opening |
35 × 35 mm |
FCR |
15% improvement |
Feed use |
10% reduction |
Antibiotics |
31% reduction |
Labor hours/tonne |
79% reduction |
Characteristic |
Significantly strong support structure. |
Feature |
Large inner space provides water flow and circulation. |
Material |
Cu |
Sn |
Al |
Zn |
Copper alloy wire |
66.0% |
0.6% |
0.6% |
Rem. |
Material |
Wire diameter |
Temper |
Hardness |
Tensile strength T/S
|
Elongation E/L
|
Copper alloy wire |
4.0 mm |
1/8 H |
54 |
440 |
22 |
Material |
Melting point
|
Gravity
|
Thermal conductivity (W/(m·K)) |
Electrical conductivity
|
Coefficient thermal expansion
|
Longitudinal modulus of elasticity
|
Copper alloy wire |
920 |
8.4 |
117 |
26 |
21 |
1.03 × 105 |
Popular Sizes |
||
Mesh Size (A) |
Wire Diameter |
Max. Width |
12.7 mm (1/2") |
0.51 mm (25#) |
1.5 m (4.9') |
15.9 mm (5/8") |
0.62 mm (23#) |
3 m (9.8') |
25.4 mm (1") |
0.91 mm (20#) |
3 m (9.8') |
25.4 mm (1") |
0.81 mm (21#) |
3 m (9.8') |
30.5 mm (1.2") |
1.01 mm (19#) |
3 m (9.8') |
30.5 mm (1.2") |
0.91 mm (20#) |
3 m (9.8') |
