Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile

Certification
China Anping yuanfengrun net products Co., Ltd certification
I'm Online Chat Now

Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile

Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile
Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile

Large Image :  Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile

Product Details:
Place of Origin: Hebei P.R. China.
Brand Name: X MESH
Certification: ISO9001:2015
Model Number: X MESH-Barbed Wire-002
Payment & Shipping Terms:
Minimum Order Quantity: 500Coil
Price: USD15-85/Coil
Packaging Details: Wrapped with plastic film and pallet packing
Delivery Time: 5-7days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000Coils/week

Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile

Description
Product Name: Barb Wire Surface Treatment: Green PVC Coated
Wire Diameter: 2.0mm Barb Type: Four Barbs
Series: Double Strand Barb Length: 20mm
Barb Spacing: 100mm Twist Type: Standard Twist Type
Tensile Strength: 1200MPa Packing: Plastic Film & Pallet Packing
High Light:

1200MPa Tensile Barb Wire

,

Green PVC Coated Barb Wire

,

Standard Twist Type Barb Wire

Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile





Barb Wire Introduction:



Types of Barbed Wire:
Single Strand: Consists of a single strand of wire with barbs attached at regular intervals. It is typically used for temporary fencing or

low-security applications.

Double Strand: Comprises two parallel strands of wire twisted together, with barbs interspersed between them. Double-strand barbed wire

offers greater security and durability than single-strand variants.

Barbed Wire Weave Type

A.double strand common twisted barbed wire.

B. single strand barbed wire.
C. double strand double twisted barbed wire.

Raw Material: Q195 q235 low carbon steel .Also Stainless steel 304 can be available.





Product Name

Barb Wire

Surface Treatment

Green PVC Coated

Wire Diameter

2.0mm

Barb Type

Four Barbs

Series

Double Strand

Barb Length

20mm

Barb Spacing

100mm

Twist Type

Standard Twist Type

Tensile Strength

1200MPa

Packing

Plastic film & Pallet Packing



Barb Wire Specifications:

The specification of barbed wire for choose:

GALVANIZED BARBED WIRE

Wire Diameter

(BWG)

Length per KG

Barb distance

3"

Barb distance

4"

Barb distance

5"

Barb space

6"

12 x 12

6.0617

6.7590

7.2700

7.6376

12 x 14

7.3335

7.9051

8.3015

8.5741

12.5 x 12.5

6.9223

7.7190

8.3022

8.7221

12.5 x 14

8.1096

8.8140

9.2242

9.5620

13 x 13

7.9808

8.8990

9.5721

10.0553

13 x 14

8.8448

9.6899

10.2923

10.7146

13.5 x 14

9.6079

10.6134

11.4705

11.8553

14 x 14

10.4569

11.6590

12.5423

13.1752

14.5 x 14.5

11.9875

13.3671

14.3781

15.1034

15 x 15

13.8927

15.4942

16.6666

17.5070

15.5 x 15.5

15.3491

17.1144

18.4060

19.3386






PVC
barbed wire

Wire Diameter

Barbs' distance

Barb length

Before coating

After coating



7.5cm - 15cm



1.5cm - 3cm

1.0mm - 3.5mm

1.4mm - 4.0mm

Bwg11 - Bwg20

Bwg8 - Bwg17

Swg11 - Swg20

Swg8 - Swg17

Other sizes can be made as request



Barb Wire Feature:

1.High protection, it is almost impossible to climb.
2.High-strength steel core very difficult to cut off.
3.Powerful security fence barriers neat appearance.
4.Extremely simple to install, needs three to four to install molding.
5.Anti-corrosion, aging, sunscreen, weather.

  • Rise in Popularity: Barbed wire gained popularity in the late 19th and early 20th centuries, particularly in the United States,

  • where it revolutionized land use and cattle ranching. It allowed for the inexpensive and efficient enclosure of vast expanses of

  • land on the American prairie.





Barb Wire Application:

widely used by many countries in prisons, detention houses, government buildings and other national security facilities.

Recently years, barbed tape has apparently become the most popular high-class fencing wire for national security applications,

but also for cottage and society fence, and other private buildings.

Security Fencing: It is also employed in various security applications, including perimeter fencing for industrial facilities, prisons, and private residences.

Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile 0



Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile 1



Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile 2



Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile 3



Green PVC Coated Barb Wire 1.5cm Barb Length Standard Twist Type 1200MPa Tensile 4
