Product Details:
|
| Color: | Silver | Material: | Aluminium |
|---|---|---|---|
| Standard: | ASTM A1011 | Width: | 1000mm |
| Cross Bar: | 5mm | Bearing Bar Pitch: | 30mm |
| Cross Bar Pitch: | 100mm | Application: | For Oil Refinery |
| Length: | 2000mm | Bearing Bar: | 25mm X 3mm |
| High Light: | aluminum bar grating 2000mm,aluminum bearing bar grating,25x3mm bearing bar grating |
||
aluminum bar grating Specifications |
|||
Item |
Description |
||
Materials |
Q235 / Stainless Steel / Aluminium |
||
Material standard |
Low carbon steel (ASTM A36, A1011, A569, S275JR, SS304, SS400,UK: 43A) |
||
Type |
Welded steel grating, pressure-locked, socket-welding |
||
Bearing bar |
20x5, 25x3, 25x4, 25x5, 30x3, 30x4, 30x5, 32x3, 32x5, 40x5, 50...75x8mm, etc. |
||
Bearing Bar's Type |
F- Plain style |
||
S-Serrated style (tooth-like) |
|||
I- I-section style |
|||
Beraing Bar Pitch |
25, 30, 30.16, 32.5, 34.3, 40, 50, 60, 62, 65mm, etc. |
||
Cross Bar |
5x5, 6x6, 8x8mm (twisted bar or round bar) |
||
Cross bar pitch |
40, 50, 60, 65, 76, 100, 101.6, 120, 130mm or as customers' requirement. |
||
Surface Treatment |
Black, Hot dip galvanized, Cold dip galvanized, Painted, Powder coated, or as customers' requirement. |
||
Galvanizing standard |
CN: GB/T13912 |
||
US: ASTM (A123) |
|||
UK: BS729 |
|||
Standards |
China: YB/T 4001.1-2007 |
||
USA: ANSI/NAAMM(MBG531-88) |
|||
UK: BS4592-1987 |
|||
Australia: AS 1657-1988 |
|||
Japan: JJS |
|||
Series No. |
Verticle Bar Spacing |
Horizontal Bar Spacing |
Specification of Supporting Flat Steel (Width X Thickness) |
||||||
|
|
|
|
20¡Á3 |
25¡Á3 |
32¡Á3 |
40¡Á3 |
20¡Á5 |
25¡Á5 |
|
1 |
30 |
100 |
G203/30/100 |
G253/30/100 |
G323/30/100 |
G403/30/100 |
G205/30/100 |
G255/30/100 |
|
|
|
|
50 |
G203/30/50 |
G253/30/50 |
G323/30/50 |
G403/30/50 |
G205/30/50 |
G255/30/50 |
|
2 |
40 |
100 |
G203/40/100 |
G253/40/100 |
G323/40/100 |
G403/40/100 |
G205/40/100 |
G255/40/100 |
|
|
|
|
50 |
G203/40/50 |
G253/40/50 |
G323/40/50 |
G403/40/50 |
G205/40/50 |
G255/40/50 |
|
3 |
60 |
50 |
- |
G253/60/50 |
G253/60/50 |
G403/60/50 |
G205/60/50 |
G255/60/50 |
|
Series No. |
Verticle Bar Spacing |
Horizontal Bar Spacing |
Specification of Supporting Flat Steel (Width X Thickness) |
||||||
|
|
|
|
32¡Á5 |
40¡Á5 |
45¡Á5 |
50¡Á5 |
55¡Á5 |
60¡Á5 |
|
1 |
30 |
100 |
G325/30/100 |
G405/30/100 |
G455/30/100 |
G505/30/100 |
G555/30/100 |
G605/30/100 |
|
|
|
|
50 |
G325/30/50 |
G405/30/50 |
G455/30/50 |
G505/30/50 |
G555/30/50 |
G605/30/50 |
|
2 |
40 |
100 |
G325/40/100 |
G405/40/100 |
G455/40/100 |
G505/40/100 |
G555/40/100 |
G605/40/100 |
|
|
|
|
50 |
G325/40/50 |
G405/40/50 |
G455/40/50 |
G505/40/50 |
G555/40/50 |
G605/40/50 |
|
3 |
60 |
50 |
G325/60/50 |
G405/60/50 |
G455/60/50 |
G505/60/50 |
G555/60/50 |
G605/60/50 |
|
