Product Details:
Place of Origin: Hebei P.R. China.
Brand Name: X MESH
Certification: ISO9001:2015
Model Number: X MESH-Gabion Wire Mesh01
Payment & Shipping Terms:
Minimum Order Quantity: 500m2
Price: USD2.00-USD5.50/m2
Packaging Details: Wrapped with plastic film and pallet packing
Delivery Time: 5-7days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000m2/week

60m By 80mm Gabion Mattress Heavy Duty Galvanized Stone Filled For River Bank

Description
Features: Simple Construction,good Permeability,etc. Product Name: Gabion Mattress
Series: ASTM A975 Standard Wire Diameter: 2.2/2.7/3.2mm
Mesh Opening: 60mm*80mm Gabion Size: 0.3m*1m*2m
Surface Treatment: Heavy Duty Galvanized Color: Silver
Type: Hexagonal Application: For River Bank
High Light:

60m by 80mm gabion mattress

,

heavy duty galvanized gabion mattress

,

river bank stone filled gabion mattress

60m by 80mm heavy duty galvanized Gabion Mattress Stone Filled for river bank



Gabion Mattress Introduction:

Gabion Mattress is a double-twisted wire mesh container of variable sizes, uniformly partitioned into internal cells, interconnected with other similar units, and filled with stone at the project site to form flexible, permeable, monolithic structures such as retaining walls, sea wall, channel linings, revetments, and weirs for erosion control projects.

Revet mattress, also called reno mattress, is also a double-twisted wire mesh container with the same weaving method as gabion baskets, only having relatively smaller height and smaller mesh openings than the mesh used for gabions. Revet mattress are generally used for riverbank protection and channel linings.

Product name

Gabion Mattress

Series

ASTM A975 Standard

Wire Diameter

2.2/2.7/3.2mm

Mesh Opening

60mm*80mm

Gabion Size

0.3m*1m*2m

Surface Treatment

Heavy Duty Galvanized

Color

Silver

Type

Hexagonal

Application

for river bank

Features

Simple construction,good permeability,etc.

Gabion Mattress Specification:

Mesh Size

Mesh Wire Dimater

Selvedge Wire

Lacing Wire

Max Width

60*80mm

2.0~2.8mm

3.0~4.0mm

2.0~2.2mm

4m

80*100mm

2.0~3.0mm

3.0~4.0mm

2.0~2.2mm

4m

80*120mm

2.0~3.0

3.0~4.0mm

2.0~2.2mm

4m

100*120mm

2.0~3.0

3.0~4.0mm

2.0~2.2mm

4m

100*150mm

2.0~3.0

3.0~4.0mm

2.0~2.2mm

4m

120*150mm

2.0~3.0

3.0~4.0mm

2.0~2.2mm

4m

Remark:Special size can be also produced at the buyer’s option.

Length

Width

Height

Number of Diaphragm

Capacity

2.0m

1.0m

0.15~0.3m

1

0.3~0.6 m³

3.0m

1.0m

0.15~0.3m

2

0.45~0.9m³

4.0m

1.0m

0.15~0.3m

3

0.6~1.2 m³

2.0m

1.0m

0.5m

1

1.0 m³

3.0m

1.0m

0.5m

2

1.5 m³

4.0m

1.0m

0.5m

3

2.0 m³

1.0m

1.0m

1.0m

0

1.0 m³

1.5m

1.0m

1.0m

0

1.5 m³

2.0m

1.0m

1.0m

1

2.0 m³

3.0m

1.0m

1.0m

2

3.0 m³

4.0m

1.0m

1.0m

3

4.0 m³

Remark:Special size can be also produced at the buyer’s option.





Gabion Mattress Standard:

Heavily zinc-coated steel wire conforming to ASTM A 641, Class 3 coating, soft temper;

Zn-5Al-MM-Coated steel wire conforming to ASTM A 856/856M, Class 3, soft temper;

The same type of metallic-coated steel wire as above, but with an additional PVC coating extruded onto the metallic-coated steel wire;

l Aluminum-coated steel wire conforming to ASTM A 809, soft temper;

The most popular wire diameter for gabion baskets is 2.7mm, 2.2mm for revet mattress.



Weaving:

a nonraveling mesh made by twisting continuous pairs of wires through three one-half turns(commonly called double-twisted) to form hexagonal-shaped openings which are then interconnected to adjacent wires to for hexagonal openings. The most popular mesh opening for gabion baskets is 80x100mm size, 60x80mm for revet mattress. During the process, a terminal wire will be used to edge the wire mesh perpendicular to the double twist by mechanically wrapping the mesh wires around it at least 2.5 times or by inserting it throughout the twists and folding one mesh length. We always use 3.4mm wire for gabion baskets, 2.7mm wire revet mattress.



Gabion Mattress Application:

retaining walls

sea wall

channel linings

revetments

and weirs for erosion control projects



60m By 80mm Gabion Mattress Heavy Duty Galvanized Stone Filled For River Bank 0



60m By 80mm Gabion Mattress Heavy Duty Galvanized Stone Filled For River Bank 1


60m By 80mm Gabion Mattress Heavy Duty Galvanized Stone Filled For River Bank 2

60m By 80mm Gabion Mattress Heavy Duty Galvanized Stone Filled For River Bank 3
