W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant

W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant
W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant

Large Image :  W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant

Product Details:
Place of Origin: Hebei P.R. China.
Brand Name: X MESH
Certification: ISO9001:2015
Model Number: X MESH-Palisade Fence09
Payment & Shipping Terms:
Minimum Order Quantity: 50sets
Price: USD25.00-75.00/Set
Packaging Details: Wrapped with plastic film and pallet packing
Delivery Time: 5-8days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 5000sets/week

W Section 68mm Security Metal Fencing Red Pvc Coated For Chemical Plant

Description
Name: Security Metal Fencing Material: Galvanized Steel
Height: 1.8m, 2.2m, 2.4m, 3.0m Width: 2.75m
Pale Thickness: 2/2.5/3mm Pale Quantity: 17
2 Pieces Of Rail Angle: 50X50X5mm Application: For Paper Plant
Feature: Crossion Resistance & Long Using Life Color: Red
High Light:

red pvc coated security metal fencing

,

chemical plant security metal fencing

,

chemical plant steel security fencing

 W Section 68mm red pvc coated Security Metal Fencing for chemical plant



Security Metal Fencing Description:

Palisade fence is a popular fence in European in the past, however, in recent years, great changes have taken place in personal aesthetic value, so the palisade fence become popular among our life. The palisade fence consists of many components, each of them is indispensable. We can provide you a complete palisade panel, we can also provide fittings separately.

Name

Security Metal Fencing

Material

Galvanized Steel

Height

1.8m, 2.2m, 2.4m, 3.0m

Width

2.75m

Pale Thickness

2/2.5/3mm

Pale Quantity

17

2 Pieces of Rail angle

50X50X5mm

Application

For paper plant

Feature

Crossion Resistance & Long Using Life

Color

Red



Security Metal Fencing Specification:

Panel size

W section pale:68mm

D section Pale:65mm

Angle Pale 56mm

Angel Rail

Post

Height

Width

Pale Thickness

Pale Quantity

2 Pieces of Rail angle

Square post

H post

1.8m

2.75m

2/2.5/3mm

17PCS

40X40X4mm

50X50X5mm

50X50X6mm

60X60mm

80X80mm

100X100mm

100X55mm

120X74mm

2.1m

2.75m

2/2.5/3mm

17PCS

2.4m

2.75m

2/2.5/3mm

17PCS

3m

2.75m

2/2.5/3/3.5mm

17PCS

Surface treatment: Galvanized or galvanized then powder coating finished

Pale head:Can be do single pointed, triple pointed, square tops, round and notched tops or rounded only.



Pales- "W" section Most using type for palisade fencing as vertical pales ,it is always the first choice for the pales .

Width

Thickness

Surface Treatment

Head

Height

68mm
-
70mm

2.0mm
2.5mm
3.0mm

Galvanized and
Electrostatic polyester powder coated or hot dipped galvanized

Single point
Triple point

1200mm

1500mm

1800mm

2000mm

2100mm

2400mm

2700mm

3000mm


Comparing with "W" profile pales , this type is more economical.

Width

Thickness

Surface Treatment

Head

Height

68mm
-
70mm

2.0mm
2.5mm
3.0mm

Galvanized and
Electrostatic polyester powder coated or hot dipped galvanized

Single point
Triple point

1200mm

1500mm

1800mm

2000mm

2100mm

2400mm

2700mm

3000mm


Its cost is similar with "D" profile ,and more simple than "D" profile.

Width

Thickness

Surface Treatment

Head

Height

40x40

2.0mm
-
3.0mm

Galvanized and
Electrostatic polyester powder coated or hot dipped galvanized

Single point

1200mm

1500mm

1800mm

2000mm

2100mm

2400mm

2700mm

3000mm



Security Metal Fencing Feature:

  • Palisade fence: One pointed, triple pointed, rounded, rounded & notched and square top.

  • Palisade gate: Singular leaf or double leaf, swing or sliding gate, cantilever gate.

  • Steel palisade fence: Made of low carbon steel, mild steel, hot or cold rolled steel.

  • Galvanized palisade fence: Palisade fence or palisade gate can be finished with hot-dipped or electric galvanized.

  • Palisade pales: The pales can be W section, D section and angle section.

  • Palisade post: The palisade posts have square type and RSJ beam type.

  • Palisade rail: Angle type with slots to fix.

  • Palisade fittings: Connecting parts include fishplates, post clamps, bolts and nuts.



Security Metal Fencing Application:



Palisade is the ideal solution for any business, school or public space in need of a strong, durable perimeter.

Powder coating in an array of colours means that this product can be matched to corporate and brand identities or

customised to assimilate with surrounding environments.



Whye Choose us:

1.Our factory specialize in design,manufacturing galvanized steel or aluminium fence, railing etc

2. Experienced sales team, engineer team, designer team and skillful workers.

3. Advanced equipment, mature production technology, strong production capability.

3. Our products surface is made of branded powder, with strong lacquer coating and strong adhsion Strict quality control system, environment friendly and anti-corrosion.

4. Perfect after-sales service,15-year maintenance.

5. Assembled product is convenient for transportation
