2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls

Certification
China Anping yuanfengrun net products Co., Ltd certification
I'm Online Chat Now

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls
2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls

Large Image :  2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls

Product Details:
Place of Origin: Hebei P.R. China.
Brand Name: X MESH
Certification: ISO9001:2015
Model Number: X MESH-Gabion Wire Mesh A10
Payment & Shipping Terms:
Minimum Order Quantity: 500m2
Price: USD2.00-USD5.50/m2
Packaging Details: Wrapped with plastic film and pallet packing
Delivery Time: 5-7days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000m2/week

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls

Description
Product Name: Gabion Wire Mesh Color: Silver
Series: Hot Galvanized Type: Hexagonal
Gabion Size: 2m*1m*1m Mesh Type: 8cm*10cm
Border Wire: 3.2mm Feature: Beautiful & Long Using Life
Application: For Landscaping Packing: Plastic Film & Pallet
High Light:

2x1x1 meters hexagonal gabion wire mesh

,

rock hexagonal gabion wire mesh

,

retaining walls hexagonal wire mesh gabion

Hexagonal Wire Mesh Wall Basket , 2x1x1meters Gabion Wire Mesh For Rock Retaining Walls



Gabion Wire Mesh Introduction:



The River Mattresses and mattresses are manufactured in strict accordance with the SANS 1580 and site installations are also in accordance with the latest SANS 1200 specification.

Our mesh is hexagonal in shape meeting with the 80×100 mm mesh aperture for gabions with a mesh wire diameter of 2.7mm and selvedge wire of 3.4mm diameter.

All measurements are in metres



Product name

Gabion Wire Mesh

Color

Silver

Series

Hot Galvanized

Type

Hexagonal

Gabion Size

2m*1m*1m

Mesh Type

8cm*10cm

Border Wire

3.2mm

Feature

Beautiful & Long using Life

Application

for Landscaping

Packing

Plastic film & Pallet



Gabion Wire Mesh Specification:

Opening
(mm)

Wire Diameter(Metal Wire) (mm)

Wire Diameter (PVC Coate)/ Inner/Outside(mm)

Strands

60X80

φ2.0-2.8

φ2.0/3.0-2.5/3.5

3

80X100

φ2.0-3.2

φ2.0/3.0-2.8/3.8

3

80X120

φ2.0-3.2

φ2.0/3.0-2.8/3.8

3

100X120

φ2.0-3.4

φ2.0/3.0-2.8/3.8

3

100X150

φ2.0-3.4

φ2.0/3.0-2.8/3.8

3

120X150

φ2.0-4.0

φ2.0/3.0-3.0/4.0

3



Typical Gabion Basket Sizes



Length, m



Width, m



Height, m

Number of

Cells, each



Volume, m³

2.0

1.0

1.0

2.0

2.0

3.0

1.0

1.0

3.0

3.0

4.0

1.0

1.0

4.0

4.0

2.0

1.0

0.5

2.0

1.0

3.0

1.0

0.5

3.0

1.5

4.0

1.0

0.5

4.0

2.0

2.0

1.0

0.3

2.0

0.6

3.0

1.0

0.3

3.0

0.9

4.0

1.0

0.3

4.0

1.2



Gabion Wire Mesh Standard:

The wire used to manufacture double twisted gabion wire mesh is soft annealed, mild steel wire provided with heavy zinc coating as per EN 10244/ASTM A 641 to prevent corrosion. In case of use in aggressive environments, it is further extruded with 0.5mm thick PVC Coating. The PVC coating is UV stabilized as per ASTM A 975.

Selvedge / Edge wire which is a thicker and heavier wire is used to reinforce the edges and transverse diaphragm. It gives greater rigidity and shape to the Gabion Basket.





Gabion Wire Mesh  Feature:

We always supply 3% lacing wire along with the material, which are used to assemble and interconnect empty units, to close and secure stone-filled units, and for internal stiffeners. Other options are available, such as fasteners, stiffeners, hog rings.



Gabion Wire Mesh Application:

  •

    • Retaining wall structures.

    • Decorative fence walls.

    • Prevention of current scour and erosion control.

    • Bridge protection.

    • Hydraulic structures, dams and culverts.

    • Embankment protection.

    • Rockfall prevention and soil erosion protection.

    • Landscaping.

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 0

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 1



2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 2

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 3

2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 4



2x1x1 Meters Hexagonal Gabion Wire Mesh For Rock Retaining Walls 5
